�Create Your Own Solution  Download the product information       1.     CL-4000, 1 or 4 HDSDI / HDMI to QAM inserter DVB-T /DVB-C or IP 2.     CL-3000, HD-SDI or SD-SDI to QAM inserter 3.     CL-2000, HD Component Video or VGA Video to QAM Inserter 4.     CL-12, 1 Video 2 or 4 or 8 Audio over fiber for up to 150Km Broadcast 5.     CL-12HD, 1 Video 2 Audio 1 ASI or 1 HD/SD -SDI to fiber 6.     CL-12SC, 1 Video 2 Audio 1 subcarrier (4.5Mhz) Audio over fiber 7.     CL-24, 2 channels Fiber Optic Video and 4 simplex audio Transmitter and Receiver 8.     CL-48, 4 Channel Video 8 Audio Fiber Optic Transmitter / Receiver up to 120Km 9.     CL-816, CL-816, 8 Baseband Video/16 Audio Fiberoptic Video Multiplexer 10.     CL-1632, 16 Baseband Video/32 Audio Fiberoptic Video Multiplexer 11.     CL-1250V, Fiberoptic Gigabit Ethernet Video/Audio Multiplexer 12.     CL-1250VHD, Gigabit Ethernet , Video/Audio ASI - SDI , HDTV fiber optic Multiplexer 13.     CL-10V, 10 Channel Video Fiberoptic Multiplexer 14.     CL-270, 1-16 DVB ASI video or SDI video Fiberoptic Transport 15.     CL-350, MPEG Transport Stream Converter 16.     CL-350S, MPEG Transport Stream Fiberoptic Converter 17.     CL-110, MPEG-2 Digital Video Decoder CL-220, MPEG-2 Digital Video Encoder 19.     CL- ASI2IP, bi-directional ASI over IP converter , IP over ASI converter 20.     CL-LBAND, L-Band 900-2100Mhz RF Transmitter/Receiver 21.     CL-5000VA, Video/Audio Card Module 22.     CL-5000DVB, DVB-ASI/SMTPE 310M Card Module 23.     CL-FOS, Automatic and Manual optical redundant failover switch 1×2, 2×1 or 2×2 24.     CL-DVI2IP, DVI or VGA over IP High Definition Encoder and Decoder 25.     CL-HDMI2IP, HDMI to IP High definition Encoder 26.     CL-HDMI-RF, HDMI true 1080p High definition wireless transmission 27.     CL-HD-ENC, HD Video / Audio - MPEG4 h.264 Encoder 28.     CL-12ASI2I, 12ASI to IP converter 29.     CL-12IP2AS, IP to up to 12 ASI converter 30.     CL-ASI2IP, ASI to IP and IP to ASI converter 31.     CL-870-T, 1310 or 1550nm Direct Modulated AGC Optical Transmitter 32.     CL-870-R-2, Optical CATV RF Reciever with Dual Internal Redundancy 33.     CL-RF-SW, 2×1 RF switch, with its high resolution to the RF monitor 34.     CL-ASIMUX, 8 x 1 DVB ASI Transport Stream Multiplexer 35.     CL-MPEG224, MPEG-2 to MPEG-4 Transcoder 36.     CL-MPEG422, MPEG-4 to MPEG-2 Transcoder 37.     CL-4100, HD/SD - SDI to ASI Real time Encoder Converter 38.     CL-4SD-ENC, (4 in 1) 4 channel Baseband Video/Audio MPEG-2 encoder with DVB ASI and IP output. 39.     CL-ASI2DS3, ASI over DS3 line Transport Uni-directional, Bi-derectional 40.     CL-HDSDI, Uncompressed HD-SDI, SD-SDI, ASI Video Audio Over Fiber 41.     CL-ASI-DA, 2, 4, 8, 16 ASI , SDI ,SMPTE310M Distribution Amplifier 42.     CL-HD-DEC, HD Video / Audio - MPEG4 h.264 Decoder 43.     CL-SD-ENC, IP and ASI TS Encoder with SD-SDI and Baseband Video / Audio input 44.     CL-ASI2E1, ASI to 4 E1 converter and 4 E1 to DVB-ASI 45.     CL2000S, VGA RGB Video to QAM Inserter with Built in Resolution Scaler �Model�� CL-220� CL-220, MPEG-2 Digital Video Encoder CL-220 is MPEG-2 encoder boasts powerful functions and high flexibility. It can be widely used in radio & TV stations, all kinds of industrial applications such as video monitoring, etc, orforhome program production. Features - Complying with ISO/IEC 11172 (MPEG-1) and ISO/IEC 13818 (MPEG-2) standards - Various A/V input modes - Forward filtering - Audio/video synchronization - MPEG-2 self-adaptive field/frame dynamic prediction and DCT - Motion prediction: 100 horizontal and 50 vertical searching - Semi-pixel precision motion statistics - TBC (Time Base Correct) - One RS-232 interface supporting independent low-rate data channel - Encoding parameters adjustment in accordance with the user's requirements - Multiple network interfaces supported - Local/remote configuration and control supported - Communication protocol and remote control software package for third-party networking and application development - Luminance/chrominance adjustment - Network access permit issued by the National Radio & TV (General) Bureau Example Aplication Model Selection CL-220-ASI/SPI MPEG-2 Digital Video Encoder, BNC/DB-25, Bit rate: 1.5-20 Mbps, Interface: DVB ASI/SPI CL-220-EP MPEG-2 Digital Video Encoder, BNC, Bit rate: 1.92 Mbps, Interface: E1 interface (ASI/SPI interface can be added) CL-220-iMUX/E1 MPEG-2 Digital Video Encoder, SMB, Bit rate: 1.5-7.6 Mbps, Interface: 1-4 channel E1 (ASI/SPI interface can be added) CL-220-IP MPEG-2 Digital Video Encoder, RJ-45, Bit rate: 1.5-7 Mbps, Interface: 10/100 Mbps Ethernet interface (ASI/SPI interface can be added) CL-220-DS3/E3 MPEG-2 Digital Video Encoder, BNC: DS3: <43 Mbps; E3: <33 Mbps, Bit rate: DS3: <43 Mbps; E3: <33Mbps, Interface: DS3 interface (default)/E3 interface Specifications Video Encoding Encoding Standards: ISO/IEC 13818 (MPEG-2), MP@ML 4:2:0, ISO/IEC 11172 (MPEG-1) Image Format: PAL, NTSC A/D Resolution: 9 bit Picture Type: I, IP, IBP, IBBP GOP Structure: adjustable Screen Size: D1, HD1, SIF, QSIF Vertical Resolution: 576 (PAL) and 480 (NTSC) Horizontal Resolution: 720 Audio Encoding Audio Encoding: ISO/IEC 11172 (MPEG-1) Layer I and II Audio Sampling Frequency: 32kHz, 44.1kHz, 48kHz A/D Resolution: 16 bit Encoding Bit Rate: 32-384 Kbps Audio Input: non-balanced analog stereo (default), balanced stereo (optional) Audio Mode: mono, stereo, dual mono, joint stereo Environment Operating temperature: 0°C to 40°C Storage temperature: -20°C to 80°C Comparative humidity: 10% to 90% (no-condensing) Power Requirements Voltage: 170V~264V/50Hzor85V~132V/60Hz, power consumption: <35W Audio/Video Input Interface Video Input: BNC: Y/C S-Video, composite, SDI (optional) Audio Interface: BNC: non-balanced stereo (default), Cannon: balanced stereo (optional)     Company : News : Solutions : Technology : Support : Clients : Contact Us
